GeoStudio deep well dewatering example: design and stability insights for engineers
Reviewed by Tom Sullivan

First reported on Geoengineer.org – News
30 Second Briefing
Dewatering design for a deep well system is modelled in GeoStudio using SEEP/W to simulate transient drawdown and quantify inflow to an excavation, with wells arranged around the perimeter and pumped to lower the groundwater table below formation level. The example compares different pumping rates and well spacings, showing effects on pore water pressures, hydraulic gradients and potential instability in adjacent slopes and structures. For practitioners, it illustrates how to test alternative layouts and pumping schedules numerically before committing to well installation on site.
Technical Brief
- SEEP/W model uses axisymmetric elements to represent individual deep wells and surrounding soil domain.
- Boundary conditions include fixed total head at the excavation base and far-field water table.
- Time-dependent pumping is simulated via specified nodal fluxes at well screens, not prescribed heads.
- Soil stratigraphy is layered with contrasting hydraulic conductivities to capture vertical flow components.
- Unsaturated behaviour above the phreatic surface is included using a soil–water characteristic curve.
- Model outputs include contour plots of hydraulic gradients to flag potential piping or heave zones.
- Sensitivity runs vary hydraulic conductivity and specific storage to bracket uncertainty in field parameters.
- Workflow mirrors staged construction: initial equilibrium, ramp-up pumping phase, then excavation advance steps.
Prepared by collating external sources, AI-assisted tools, and Geomechanics.io’s proprietary mining database, then reviewed for technical accuracy & edited by our geotechnical team.
